We were at X-IO Technologies last week for SFD13 in Colorado Springs talking with the team and they showed us their new IO and storage intensive server, the Axellio. They want to sell Axellio to customers that need extreme IOPS, very high bandwidth, and large storage requirements. Videos of X-IO’s sessions at SFD13 are available here.

The hardware

Axellio comes in 2U appliance with two server nodes. Each server supports  2 sockets of Intel E5-26xx v4 CPUs (4 sockets total) supporting from 16 to 88 cores. Each server node can be configured with up to 1TB of DRAM or it also supports NVDIMMs.

There are two key differentiators to Axellio:

1. The FabricExpress™, a PCIe based interconnect which allows both server nodes to access dual-ported,  2.5″ NVMe SSDs; and
2. Dense drive trays, the Axellio supports up to 72 (6 trays with 12 drives each) 2.5″ NVMe SSDs offering up to 460TB of raw NVMe flash using 6.4TB NVMe SSDs. Higher capacity NVMe SSDS available soon will increase Axellio capacity to 1PB of raw NVMe flash.

They also probably spent a lot of time on packaging, cooling and power in order to make Axellio a reliable solution for edge computing. We asked if it was NEBs compliant and they told us not yet but they are working on it.

Axellio can also be configured to replace 2 drive trays with 2 processor offload modules such as 2x Intel Phi CPU extensions for parallel compute, 2X Nvidia K2 GPU modules for high end video or VDI processing or 2X Nvidia P100 Tesla modules for machine learning processing. Probably anything that fits into Axellio’s power, cooling and PCIe bus lane limitations would also probably work here.

At the frontend of the appliance there are 1x16PCIe lanes of server retained for networking that can support off the shelf NICs/HCAs/HBAs with HHHL or FHHL cards for Ethernet, Infiniband or FC access to the Axellio. This provides up to 2x100GbE per server node of network access.

Performance of Axellio

With Axellio using all NVMe SSDs, we expect high IO performance. Further, they are measuring IO performance from internal to the CPUs on the Axellio server nodes. X-IO says the Axellio can hit >12Million IO/sec with at 35µsec latencies with 72 NVMe SSDs.

Lab testing detailed in the chart above shows IO rates for an Axellio appliance with 48 NVMe SSDs. With that configuration the Axellio can do 7.8M 4KB random write IOPS at 90µsec average response times and 8.6M 4KB random read IOPS at 164µsec latencies. Don’t know why reads would take longer than writes in Axellio, but they are doing 10% more of them.

Furthermore, the difference between read and write IOP rates aren’t close to what we have seen with other AFAs. Typically, maximum write IOPs are much less than read IOPs. Why Axellio’s read and write IOP rates are so close to one another (~10%) is a significant mystery.

As for IO bandwitdh, Axellio it supports up to 60GB/sec sustained and in the 48 drive lax testing it generated 30.5GB/sec for random 4KB writes and 33.7GB/sec for random 4KB reads. Again much closer together than what we have seen for other AFAs.

Also noteworthy, given PCIe’s bi-directional capabilities, X-IO said that there’s no reason that the system couldn’t be doing a mixed IO workload of both random reads and writes at similar rates. Although, they didn’t present any test data to substantiate that claim.

Markets for Axellio

They really didn’t talk about the software for Axellio. We would guess this is up to the customer/vertical that uses it.

Aside from the obvious use case as a X-IO’s next generation ISE storage appliance, Axellio could easily be used as an edge processor for a massive fabric of IoT devices, analytics processor for large RT streaming data, and deep packet capture and analysis processing for cyber security/intelligence gathering, etc. X-IO seems to be focusing their current efforts on attacking these verticals and others with similar processing requirements.

X-IO Technologies’ sessions at SFD13

Other sessions at X-IO include: Richard Lary, CTO X-IO Technologies gave a very interesting presentation on an mathematically optimized way to do data dedupe (caution some math involved); Bill Miller, CEO X-IO Technologies presented on edge computing’s new requirements and Gavin McLaughlin, Strategy & Communications talked about X-IO’s history and new approach to take the company into more profitable business.

Again all the videos are available online (see link above). We were very impressed with Richard’s dedupe session and haven’t heard as much about bloom filters, since Andy Warfield, CTO and Co-founder Coho Data, talked at SFD8.

For more information, other SFD13 blogger posts on X-IO’s sessions:

• SFD13 primer – X-IO Axellio Edge Computing Platform by Max Mortillaro (@Darkkavenger)
• X-IO Technology – a #SFD13 preview by Mike Preston (@mwpreston)

Full Disclosure

X-IO paid for our presence at their sessions and they provided each blogger a shirt, lunch and a USB stick with their presentations on it.
